| SPECIFICATION |
| Dimension |
3400 * 1200 * 1800 MM |
| F/R Track |
860 / 970MM |
| Wheelbase |
2260MM |
| Ground Clearance |
114MM |
| Min. Turning Radius |
3.6M |
| Net Weight |
560KG |
| Pay Load |
600KG |
| Climbing Capacity (FULL LOAD) |
25% |
| Chassis |
Steel Chassis |
| Body Cover |
PP Engineering Plastic |
| Max. Forward Speed |
24 KM/H |
| Range |
50-70KM |
| Cargo Size & Up Angle |
1200 * 1700 * 250 MM ; 25 ° |
| CONFIGURATION |
| Motor |
ADC Separately excited motor 48V 3.7KW |
| Controller |
curtis controller 48V 275A |
| Batteries |
T-875 6*8V |
| Charger |
48V 17A Regulator |
| CHASSIS CONFIGURATION |
| Transaxle |
Italy Graziano Axle |
| Brake System |
Rear Self-adjusting drum brake |
| Steering System |
Dual Self-adjusting Rack & Pinion |
| F/R Suspension |
Mcpherson independent spring suspension |
| Tyre |
10 inches |
